Ubiquiti Wave-AP-Gen2 60 GHz + 5 GHz multipoint Base Station

This highly compact device is also equipped with an integrated GPS, Bluetooth for easy initial setup via the UISP mobile app, a 2.5 Gigabit LAN port with PoE support, and an SFP+ port. The device only supports bridge mode and in the 60GHz spectrum supports 540, 1080, and 2160 MHz channel widths. The maximum throughput stated by the manufacturer is 5.4Gbps (2.7Gbps full duplex).

• Compact size – 287 × 158 × 100 mm
• 60GHz low-interference spectrum – 57 to 71 GHz
• Range up to 6km – depending on regulations in the country of use, supports up to 31 clients
• Throughput of 5.4Gbps (2.7Gbps FD)
• Supports 540 and 1024 MHz channel widths for longer distance or better performance in poor weather conditions
• Supported channels: 58320, 59400, 60480, 61560, 62640, 63720, 64800, 65880, 66960, 68040, 69120, 70200 MHz – depending on location
• 2.5 Gigabit LAN port with passive PoE support (24 or 48V DC) + 1x SFP+ (1/10 Gbps)
• Built-in GPS
• Configuration via web management and Bluetooth – UISP mobile app
